What Size Grout Line for Subway Tile: A Practical Guide
Learn how to pick the right grout line for subway tile—typical widths, factors that influence size, and a step-by-step method to get perfect joints.
To achieve a visually balanced subway tile install, target a grout line around 1/16 to 1/8 inch. Tile edge bevels, tile flatness, and wall tolerances influence the final width, so always verify width on a sample panel before full installation.
What the right grout line does for subway tile
Subway tile offers a classic look that relies on clean lines and consistent spacing. The size of the grout line matters not just for aesthetics but for longevity and maintenance. A width that's too narrow can make cleaning difficult and increase the risk of discoloration from soap scum and mold. A width that's too wide can overpower the tile pattern and create more prominent grout lines that may require more grout and sealant over time. For standard residential installations, aiming for a width between 1/16 inch (about 1.5-2 mm) and 1/8 inch (about 3 mm) provides a balance between visual rhythm and practical cleaning. This range accommodates minor tile thickness variations and room movement without compromising joint integrity. According to Grout Maintenance, the right grout line helps maintain uniform color and makes routine maintenance easier.
Why tile size, manufacturing tolerances, and bevels influence grout width
Tile edges vary due to manufacturing tolerances and format sizes; a small variation in tile thickness or bevel can push the grout width in one joint wider on one tile and narrower on the next. If you have a bevel on subway tile, the bevel edge can trap dirt and can visually reduce the perceived grout width; You might need to adjust width slightly to keep joints consistent across a wall. The grout width should be planned with the entire surface in mind, not tile by tile. The grout line should help the pattern read evenly from a distance, and for large panels, consistency across sections helps the install look deliberate. If different tile batches occur, measure several tiles and adjust to the widest joint while still staying within the acceptable range.
Typical widths for common subway tile configurations
Most ceramic subway tile used in homes is 3x6 or 4x8; For these, a 1/16 inch to 1/8 inch grout line is common. Unsanded grout is typically used for widths at or below 1/8 inch, while slightly wider joints may benefit from sanded grout to reduce cracking. In showers or humid spaces, an 1/8 inch width is often preferred because it maintains a robust joint that resists mildew when properly sealed. Tile bevels and edge profiles influence the perceived width; tight edge tolerances on some brands can make a narrower joint preferable, while beveled or slightly thicker tiles might justify a wider joint to preserve a consistent look across a wall.
How to measure and plan your grout width
Begin by measuring actual tile thickness with calipers on multiple tiles from the same box. Record the minimum, maximum, and average thickness, and note any bevels or edge profiles. Do a dry layout on a small wall panel using spacers to simulate the final joint width. This mock-up helps identify inconsistencies before you commit to a full install. Check whether your backer board, wall straightness, and substrate movement could affect joint width over time. If you find a discrepancy, choose a width that accommodates the widest variation while remaining within the typical range.
Finishing touches: sealing and maintenance considerations
After grouting, let the joints cure according to the grout manufacturer’s instructions (usually 24–72 hours for initial cure). In moisture-prone areas, sealing the grout can help prevent staining and mildew, but follow the sealant manufacturer’s guidelines for application on pre-sealed tiles. Regular cleaning with a non-abrasive cleaner helps preserve color uniformity and joint width appearance. Remember that sealant performance can depend on grout type (unsanded vs. sanded) and local humidity.
Tools & Materials
- Tile spacers (assorted thickness: 1/16 in, 1/8 in)(Keep for consistent grout width across tiles)
- Grout float (rubber)(For pressing grout into joints without tearing the tile surface)
- Caliper or precision ruler(To verify grout line width within 1/64 in accuracy)
- Grout (unsanded for narrow widths; sanded for wider lines)(Follow manufacturer color and mix instructions)
- Straight edge or level(Helps verify wall flatness and joint consistency)
- Sponges, buckets, clean water(Used to clean excess grout during initial set)
- Protective gloves and safety glasses(Personal protection during mixing and grouting)
- Grout sealer (optional)(Apply after full cure if you want extra stain resistance)
Steps
Estimated time: Estimated total active time: 2-3 hours; plus cure time of 24–72 hours depending on grout type
- 1
Inspect layout and plan width
Assess tile edges, bevels, and wall tolerances. Decide on a target width in the 1/16 to 1/8 inch range, and plan a test panel to confirm looks before full installation.
Tip: Mark a small section with painter's tape to visualize the joint width on real tiles. - 2
Select grout type and thickness
Choose unsanded grout for widths up to 1/8 inch; if tiles or edges vary, consider a slightly wider joint and a sanded grout. Prepare small batches and test color on a mock-up.
Tip: Use a grout color lighter or darker than the tile to enhance line visibility. - 3
Dry layout and spacing
Lay out tiles on a dry backer board or wall section with spacers to simulate the final look. Check alignment and confirm that the joints read evenly from typical viewing angles.
Tip: Take a few steps back to assess the rhythm of the joints across the panel. - 4
Mix and apply grout
Mix grout to manufacturer specs and apply with a float, pressing grout into joints. Work in 2–3 ft sections to maintain control of width and prevent skinning.
Tip: Keep joints evenly filled and avoid dragging grout across multiple joints at once. - 5
Clean excess grout and adjust width
After initial set, wipe the tile surface with a damp sponge to remove haze and refine joint width. If any joints appear uneven, touch up while grout is still workable.
Tip: Rinse sponge frequently to avoid re-depositing grout on the tile face. - 6
Cure and seal
Allow grout to cure per instructions (usually 24–72 hours). Apply sealer if recommended and clean the surface. Schedule final inspection after curing for any touch-ups.
Tip: Do not expose grout to water during the initial cure period.
Got Questions?
What is the recommended grout width for subway tile?
Typically, 1/16 inch to 1/8 inch is recommended for subway tile. This range balances aesthetics with ease of cleaning and durability. Always test on a sample panel that matches your tiles.
For subway tile, aim for about 1/16 to 1/8 of an inch in width. Always test a small panel first to be sure it looks right on your wall.
Does tile bevel affect grout width?
Yes. Beveled edges can influence the perceived width and trap debris if too narrow. If your tiles have bevels, you may need to lean toward the wider end of the typical range to keep joints even.
Bevels can make joints appear narrower or uneven, so consider the wider end of the range when bevels exist.
Can I change grout width after installation?
Once grout sets, changing width is difficult and may require regrouting. If you’re unsure, perform a larger test panel and adjust before grouting the full area.
After grout sets, changing width is tough. Always test a panel before grouting the whole area.
What if tile sizes are inconsistent?
Measure several tiles and plan around the widest thickness and most pronounced bevel. Use spacers to maintain uniform width across the panel, and adjust as needed within the typical range.
If sizes vary, pick a width that accommodates the thickest tile and keep it consistent with spacers.
Should I seal grout before grouting?
Sealing before grouting is not recommended. Apply sealant after the grout has fully cured to avoid trapping moisture and compromising joint adhesion.
Seal after curing, not before grouting.
How can I fix an uneven grout width after installation?
If width looks uneven after curing, identify whether it’s a tile edge, bevel, or substrate issue. Small touch-ups with epoxy-based filler are possible, but major adjustments require regrouting.
If it’s uneven, assess the cause and consider a careful touch-up or regrouting for large inconsistencies.
Watch Video
The Essentials
- Plan grout width within 1/16–1/8 inch range.
- Use dry-layout tests to confirm uniformity before grouting.
- Consider tile bevel and thickness variations in width decisions.
- Seal and maintain grout after curing for longevity.
